Box Feeder, Steel Plate Belts
for bunkering and dosing
Designs
Dimensions
- Centre-to-centre distance: up to 25.0 m
- Plate width: up to 2.25 m
- Filling weight: up to 200 t
- Individual weight: up to 50.0 t
Box feeder accessories
- Pre-cutter
- Attachment hopper
- Plastic lining
- Steel substructure
- Load cells
Filler box
Hopper sheets and bracing elements in HEA profile
Feeder belt
1. arched sheets, s = 6 mm
2. steel shingle conveyor, e = 160 mm + 200 mm attached laterally to chain
3. conveyor belt, robust, with support rollers as “table”
Lubrication
Fully automatic dripping oiler for chains
Base frame
HEA profile steel
Drive
SEW bevel gear motor to be controlled with FU, drive shaft Ø up to 240 mm
Stripper
heavy stripper plate in welded steel
Reel
Steel shafts with screw-shape attached reel arms and drive
Shaft bearing
Drive: SKF bearing casing SNH
Redirection: radial insert ball bearings
Reel: reinforced vertical bearings
